Single Fish Eye Assembly

Get a Price/Quote

Single Fish Eye Assembly Specification

Noise Level
Silent Operation

Features
Leak proof, corrosion resistant, clear visual inspection window

Usage & Applications
Used in industrial pipelines for visual inspection and monitoring of fluid flow

Shape
Round with flat flanges

Size
Standard/Custom Available

Surface Finish
Smooth, Glossy

Drive Type
Flanged/Bolted

Product Type
Single Fish Eye Assembly

Material
Stainless Steel

Technology
Precision Machined

Power Source
Manual/Mechanical

Pressure
Up to 10 bar

Dimension (L*W*H)
75 mm x 75 mm x 90 mm (approx.)

Weight
1.2 kg (approx.)

Color
Metallic Silver

About Single Fish Eye Assembly

Single Fish Eye Assembly:-

We offer wide range of Single Fish Eye Assembly . Our Single Fish Eye Assembly are manufactured from quality material and can be availed as per the requirement of the client at leading price.

Robust Construction and Versatile Installation

Featuring tempered borosilicate glass and stainless steel, the Single Fish Eye Assembly delivers strength and resilience in demanding environments. Its compact design and universal mounting orientation allow installation in both horizontal and vertical pipelines, accommodating diverse process needs. Flanged connections as per ANSI/DIN standards ensure reliable integration and leak-proof performance.

Unmatched Chemical Resistance and Clear Inspection

The inspection window, available in standard or custom sizes, provides unobstructed visibility for fluid monitoring. Resistant to acids, alkalis, and solvents, the assembly maintains integrity and clarity even in hostile process conditions. This precision-machined solution offers silent operation and smooth, glossy surfaces for optimal hygiene.

FAQs of Single Fish Eye Assembly:

Q: How is the Single Fish Eye Assembly installed in industrial pipelines?

A: The assembly supports both horizontal and vertical installation using flanged end connections as per ANSI/DIN standards. Its universal mounting orientation enables easy integration into various pipeline systems.

Q: What are the primary benefits of using tempered borosilicate glass for the inspection window?

A: Tempered borosilicate glass provides high chemical resistance, thermal stability, and clear visual inspection. It ensures durability when exposed to acids, alkalis, solvents, and high-pressure conditions up to 10 bar.

Q: When should I consider customizing the inspection window diameter or size?

A: Customization is recommended when specific process requirements demand a different inspection diameter or unit size for better visibility or integration. Standard diameter is 40 mm, but options are available upon request.

Q: Where can the Single Fish Eye Assembly be used?

A: It is ideal for use in industrial pipeline systems across diverse industries such as chemical processing, pharmaceuticals, water treatment, and food productionanywhere fluid flow needs to be visually monitored.

Q: What is the procedure for maintaining the assembly to achieve optimal life expectancy?

A: Routine inspections for physical integrity, proper sealing, and cleanliness are recommended. Ensure no accumulation of deposits or corrosion, and replace protective covers as needed to safeguard the glass window.

Q: How does the assembly ensure silent operation and leak-proof performance?

A: Precision machining, robust stainless steel design, and quality flanged connections contribute to a silent, leak-proof system, preventing fluid or pressure loss and enabling reliable monitoring without noise.

Q: What are the advantages of choosing this product for chemical compatibility and corrosion resistance?

A: The combination of borosilicate glass and stainless steel provides outstanding resistance to aggressive chemicals and corrosion, ensuring longevity and continuous clear visibility in pipeline inspection applications.
